In stock & forged to order
The wear parts we supply
MRE-WP-CR
MRE-WP-WI
MRE-WP-SK
MRE-WP-WR
MRE-CP-CLMRE-WP-SPCutting rings, wear plates, wearing inserts and seal kits for Schwing and Putzmeister concrete pumps. Made in our own Ahmedabad works, with a material certificate on every batch.
Send your part number on WhatsApp →MRE-WP-CRMRE-WP-WIMRE-WP-SKMRE-WP-WRMRE-CP-CLMRE-WP-SPFits column shows Schwing models. RL = rock-valve generation. Confirm your model on enquiry.
| OEM Part No. | Description | Fits (Schwing) |
|---|---|---|
| Clamp / Coupling | ||
| 10007018 | CLAMP CUP-TYPE 5 1/2” fl st neti te nei cr ves | KVM32XL |
| 10043559 | CLAMP, CUP TYPE, TENSION DN 150 WEDGE | BP1800, BP350, KVM32XL, S17, S20, S36X, SP1400, SP1800 |
| 10043560 | CLAMP, CUP TYPE, TENSION DN 180 WEDGE | BP1800 |
| Cutting Ring | ||
| 10001724 | Cutting ring S-R 6 LL | S36X |
| 10063939 | CUTTING RING DN 210 | BP1800, S17 |
| 10181916 | CUTTING RING DN 220 | S36X |
| 10308236 | CUTTING RING DN190 | S20, S36X, SP1400, SP1800 |
| 80006953 | CUTTING RING (TYPE1) | S36X |
| Wearing Insert | ||
| 10074767 | Wearing insert DN200 | BP1800 |
| 10074768 | WEARING INSERT DN 230 | S36X |
| 10308231 | WEARING INSERT RL | S20, S36X, SP1400, SP1800 |
| 80006952 | WEARING INSERT (TYPE1) | S36X |
| Delivery Pipe | ||
| 10004542 | TAPER PIPE DN 150/125 | BP350 |
| 10007503 | TAPER PIPE DN 180/150 | BP350 |
| 10088570 | Pipe DN125 5 1/2 | S36X |
| 10211701 | DELIVERY PIPELINE S 17-125 | S17 |
| 60406223 | Flanged pipe DN125= 140 | D_KMAT_HN225 |
| 80004800 | DELIVERY PIPELINE S20 - DN125 | S20 |
| Bend / Elbow DN125 | ||
| 10081211 | BEND DN125 5 1/2" 45° | S36X |
| 10081212 | ELBOW DN125 5 1/2" 90 DEG | S36X |
| 10096664 | ELBOW DN125 5 1/2" 90° S2000 100MM EXTEN | S36X |
| 10150592 | ELBOW DN125 5 1/2" 50° S2000 | S36X |
| 10187150 | ELBOW DN125 5 1/2" 90° S3000 | S36X |
| 10189900 | ELBOW DN125 5 1/2" 90° S3000 | S36X |
| 10189901 | ELBOW DN125 5 1/2" 45° S3000 | S36X |
| 10190499 | ELBOW DN125 5 1/2" 90° S3000 100MM EXTEN | S36X |
| Bend / Elbow DN150 | ||
| 10091923 | BEND DN150 90° | S20, S36X |
| 10204750 | ELBOW DN150 V-R 90° S3000 | S36X |
| 80004811 | HINGED ELBOW DN150, MACHINED | S36X |
| Seal Kit | ||
| 10003413 | GROOVED RING SEALING SET 45/65 X 27.5 | BP350 |
| 10003421 | SEALING GLAND SET | BP1800, S17, S36X, SP1800 |
| 10007414 | SEALING GLAND SET 45/65 X 27.5 | BP350 |
| 10016235 | PISTON SEALING SET 80 X 60 X 10 | BP1800, S17, S36X |
| 10022378 | PISTON SEALING SET | S36X |
| 10038134 | CYLINDER SEALING SET | S36X |
Compatible aftermarket parts. Numbers are Putzmeister OEM references shown for identification — we are not an authorised Putzmeister dealer.
| OEM Ref. | Description (Duro 11 / Duro 22 / Hard Metal) |
|---|---|
| 229488005 | Spectacle Wear Plate DURO22 |
| 251031006 | Wear Ring DURO22 |
| 485385 | Spectacle Wear Plate ND200/260 Hard Metal |
| 531240 | Wear Ring |
| 261122002 | Spectacle Wear Plate DURO22 |
| 261123001 | Wear Ring Big Mouth Cutting Ring, DURO22 |
| 531499 | Spectacle Wear Plate |
| 494520 | Wear Ring Big Mouth Cutting Ring, Ø 230 |
| 251231000 | Wear Ring Duro 11 and Duro 22 |
| 509425 | Wear Ring Hard Metal |
| 087722000 | Spectacle Wear Plate Duro 11, 180mm x 260mm |
| 234559000 | Spectacle Wear Plate Duro 22 |
| 406927 | Spectacle Wear Plate Duro 22, Hole pattern 570, Whit |
| 519314 | Spectacle Wear Plate Duro 22, Hole pattern 540, Gray |
| A527212 | Wear Ring DN 210 |
| A527255 | Wear Ring DN 220 |
| A531283 | Wear Ring DN 165 |
| 269759008 | Wear Ring DN180 Carbide |
| 430408 | Wear Ring ND150ZI180 |
| 430406 | Spectacle Wear Plate D150/160 DURO 22 |
Send your Schwing or Putzmeister part number, or a photo, on WhatsApp.
or email mre_ahd@yahoo.co.in
